- PT1 防塵密封圈 液壓 密封件
訂購致電:0755-28545652 手機:13602589346
標準材料,異形圈:填充聚四氟乙烯F-PTFE或聚氨酯PU,O形圈:丁腈橡膠NBR或氟橡膠FKM
應用范圍:由一個帶密封刃口和防塵刃口的異行圈以及2個O形圈組成的PT1防塵圈用于改善整體密封性,具有低摩擦,無粘滑現象.在工作中有極好的調節和定位能力.可用于農業機械、液壓機、注塑機、液壓控制系統、叉車、起重機、滾軋、裝卸機械等設備.
設計時可參考Trelleborg公司W(wǎng)EMHF系列、Merkel公司PT1系列標準.
特點:雙唇口防塵圈用于改善整體密封性,低摩擦，低粘性摩擦,在工作出過程中有極好的調節和定位能力,對于行程短和頻率高條件下使用的防塵圈可以變換材料定做,可靠性高，在短時間內能接受滿負荷的工作壓力
工況條件
應用范圍:由一個帶密封刃口和防塵刃口的異行圈以及2個O形圈組成的PT1防塵圈用于改善整體密封性,具有低摩擦,無粘滑現象.在工作中有極好的調節和定位能力.可用于農業機械、液壓機、注塑機、液壓控制系統、叉車、起重機、滾軋、裝卸機械等設備.
設計時可參考Trelleborg公司W(wǎng)EMHF系列、Merkel公司PT1系列標準.
特點:雙唇口防塵圈用于改善整體密封性,低摩擦，低粘性摩擦,在工作出過程中有極好的調節和定位能力,對于行程短和頻率高條件下使用的防塵圈可以變換材料定做,可靠性高，在短時間內能接受滿負荷的工作壓力
工況條件
|
速 度 |
壓力范圍 |
溫度范圍 |
介 質 |
可供直徑范圍 |
|
|
- |
|
石油基液壓油，難燃液壓液，環保安全液壓液（生物油）、水和其它 |
20 |
|
軸徑 |
溝槽直徑 |
槽寬 |
臺徑 |
導向長度 |
圓角 |
|
d f8 |
D H9 |
L+0.2 |
D1±0.1 |
L1 |
r |
|
20-39.9 |
d+7.6 |
4.2 |
d+1.0 |
8.2 |
0.4 |
|
40-69.9 |
d+8.8 |
6.3 |
d+1.5 |
10.3 |
1.2 |
|
70-139.9 |
d+12.2 |
8.1 |
d+2.0 |
12.1 |
2.0 |
|
140-399.9 |
d+16.0 |
11.5 |
d+2.0 |
15.5 |
2.0 |
|
400-649.9 |
d+24.0 |
15.5 |
d+2.5 |
19.5 |
2.0 |
|
650-999.9 |
d+27.3 |
18.0 |
d+2.5 |
23.0 |
2.0 |
| PT1 防塵圈 >>>>>>>>>>>>格萊圈(格來圈)的安裝方法 | |||||||||||||
訂貨號 |
d f8 |
D H9 |
H |
L+0.2 |
訂貨號 |
d f8 |
D H9 |
H |
L+0.2 |
||||
PT1-0200 |
20 |
27.6 |
4.0 |
4.2 |
PT1-2450 |
245 |
261 |
11.0 |
11.5 |
||||
PT1-0250 |
25 |
32.6 |
4.0 |
4.2 |
PT1-2500 |
250 |
266 |
11.0 |
11.5 |
||||
PT1-0280 |
28 |
35.6 |
4.0 |
4.2 |
PT1-2600 |
260 |
276 |
11.0 |
11.5 |
||||
PT1-0300 |
30 |
37.6 |
4.0 |
4.2 |
PT1-2800 |
280 |
296 |
11.0 |
11.5 |
||||
PT1-0320 |
32 |
39.6 |
4.0 |
4.2 |
PT1-2900 |
290 |
306 |
11.0 |
11.5 |
||||
PT1-0350 |
35 |
42.6 |
4.0 |
4.2 |
PT1-3000 |
300 |
316 |
11.0 |
11.5 |
||||
PT1-0360 |
36 |
43.6 |
4.0 |
4.2 |
PT1-3200 |
320 |
336 |
11.0 |
11.5 |
||||
PT1-0400 |
40 |
48.8 |
6.0 |
6.3 |
PT1-3400 |
340 |
356 |
11.0 |
11.5 |
||||
PT1-0420 |
42 |
50.8 |
6.0 |
6.3 |
PT1-3550 |
355 |
371 |
11.0 |
11.5 |
||||
PT1-0450 |
45 |
53.8 |
6.0 |
6.3 |
PT1-3600 |
360 |
376 |
11.0 |
11.5 |
||||
PT1-0500 |
50 |
58.8 |
6.0 |
6.3 |
PT1-3700 |
370 |
386 |
11.0 |
11.5 |
||||
PT1-0550 |
55 |
63.8 |
6.0 |
6.3 |
PT1-3750 |
375 |
391 |
11.0 |
11.5 |
||||
PT1-0560 |
56 |
64.8 |
6.0 |
6.3 |
PT1-3800 |
380 |
396 |
11.0 |
11.5 |
||||
PT1-0600 |
60 |
68.8 |
6.0 |
6.3 |
PT1-3900 |
390 |
406 |
11.0 |
11.5 |
||||
PT1-0630 |
63 |
71.8 |
6.0 |
6.3 |
PT1-4000 |
400 |
424 |
14.8 |
15.5 |
||||
PT1-0650 |
65 |
73.8 |
6.0 |
6.3 |
PT1-4100 |
410 |
434 |
14.8 |
15.5 |
||||
PT1-0700 |
70 |
82.2 |
7.7 |
8.1 |
PT1-4200 |
420 |
444 |
14.8 |
15.5 |
||||
PT1-0750 |
75 |
87.2 |
7.7 |
8.1 |
PT1-4300 |
430 |
454 |
14.8 |
15.5 |
||||
PT1-0800 |
80 |
92.2 |
7.7 |
8.1 |
PT1-4400 |
440 |
464 |
14.8 |
15.5 |
||||
PT1-0850 |
85 |
97.2 |
7.7 |
8.1 |
PT1-4500 |
450 |
474 |
14.8 |
15.5 |
||||
PT1-0900 |
90 |
102.2 |
7.7 |
8.1 |
PT1-4600 |
460 |
484 |
14.8 |
15.5 |
||||
PT1-1000 |
100 |
112.2 |
7.7 |
8.1 |
PT1-4700 |
470 |
494 |
14.8 |
15.5 |
||||
PT1-1100 |
110 |
122.2 |
7.7 |
8.1 |
PT1-4800 |
480 |
504 |
14.8 |
15.5 |
||||
PT1-1150 |
115 |
127.2 |
7.7 |
8.1 |
PT1-5000 |
500 |
524 |
14.8 |
15.5 |
||||
PT1-1200 |
120 |
132.2 |
7.7 |
8.1 |
PT1-5100 |
510 |
534 |
14.8 |
15.5 |
||||
PT1-1250 |
125 |
137.2 |
7.7 |
8.1 |
PT1-5200 |
520 |
544 |
14.8 |
15.5 |
||||
PT1-1300 |
130 |
142.2 |
7.7 |
8.1 |
PT1-5300 |
530 |
554 |
14.8 |
15.5 |
||||
PT1-1400 |
140 |
156 |
11.0 |
11.5 |
PT1-5400 |
540 |
564 |
14.8 |
15.5 |
||||
PT1-1500 |
150 |
166 |
11.0 |
11.5 |
PT1-5600 |
560 |
584 |
14.8 |
15.5 |
||||
PT1-1600 |
160 |
176 |
11.0 |
11.5 |
PT1-5900 |
590 |
614 |
14.8 |
15.5 |
||||
PT1-1700 |
170 |
186 |
11.0 |
11.5 |
PT1-6000 |
600 |
624 |
14.8 |
15.5 |
||||
PT1-1800 |
180 |
196 |
11.0 |
11.5 |
PT1-6200 |
620 |
644 |
14.8 |
15.5 |
||||
PT1-2000 |
200 |
216 |
11.0 |
11.5 |
PT1-6900 |
690 |
717.3 |
17.2 |
18 |
||||
PT1-2200 |
220 |
236 |
11.0 |
11.5 |
PT1-7600 |
760 |
787.3 |
17.2 |
18 |
||||
PT1-2300 |
230 |
246 |
11.0 |
11.5 |
PT1-8000 |
800 |
827.3 |
17.2 |
18 |
||||
PT1-2400 |
240 |
256 |
11.0 |
11.5 |
PT1-9000 |
900 |
927.3 |
17.2 |
18 |
||||
