- 孔用斯特封 GSD密封圈 液壓 密封件
訂購致電:0755-28545652 手機:13602589346
標準材料,密封環:填充聚四氟乙烯F-PTFE,O形圈:丁腈橡膠NBR或氟橡膠FKM應用范圍:液壓系統、往復運動，在高壓和低壓及高頻工況下的重載雙向活塞密封場合非常出色。適用在長及短行程的情況，并在范圍較廣的流體和高溫場合，可適用較大的活塞間隙。例如用在推土機、壓機和其它機床等。符合ISO 7425/1標準。設計選用時可參考Trelleborg公司PS系列、Merkel公司OMK-E系列、Parker公司OG系列、AS公司的YAB系列標準。
特點:良好的動靜密封性能,抗擠出性好,尺寸穩定,不受溫度影響,不會發生困壓,可多只安裝,對強沖擊系統有優異的緩沖的作用,摩擦力小,無爬行現象,無粘現象,耐腐蝕性強,溝槽結構簡單,壽命長.
工況條件
|
速 度 |
壓力范圍 |
溫度范圍 |
介 質 |
可供直徑范圍 |
|
|
0～60MPa |
|
石油基液壓油、難燃液壓液、環保安全液壓液（生物油）、水和其它，取決于密封圈材質 |
8 |
|
軸徑DN H9 |
溝槽外徑 |
溝槽寬度 |
圓角 |
徑向間隙 S max |
0形圈截面 |
||||
|
標準規格 |
輕型 |
重型 |
d1 h9 |
L1+0.2 |
r1 |
10 MPa |
20 MPa |
40 MPa |
d2 |
|
8-16.9 |
17-26.9 |
- |
DN-4.9 |
2.2 |
0.4 |
0.3 |
0.20 |
0.15 |
1.78 |
|
17-26.9 |
27-59.9 |
- |
DN-7.3 |
3.2 |
0.6 |
0.4 |
0.25 |
0.15 |
2.62 |
|
27-59.9 |
60-199.9 |
17-26.9 |
DN-10.7 |
4.2 |
1.0 |
0.4 |
0.25 |
0.20 |
3.53 |
|
60-199.9 |
200-255.9 |
27-59.9 |
DN-15.1 |
6.3 |
1.3 |
0.5 |
0.30 |
0.20 |
5.33 |
|
200-255.9 |
256-669.9 |
60-199.9 |
DN-20.5 |
8.1 |
1.8 |
0.6 |
0.35 |
0.25 |
7.00 |
|
256-669.9 |
670-99.9 |
200-255.9 |
DN-24.0 |
8.1 |
1.8 |
0.6 |
0.35 |
0.25 |
7.00 |
|
670-999.9 |
- |
256-669.9 |
DN-27.3 |
9.5 |
2.5 |
0.7 |
0.50 |
0.30 |
8.40 |
|
>1000 |
DN-38.0 |
13.8 |
3.0 |
1.0 |
0.70 |
0.60 |
12.00 |
||
| GSD 孔用斯特封 >>>>>>>>>>>>孔用斯特封的安裝方法 | |||||||||||||
| 訂貨號 | 缸徑 | 溝槽底徑 | 寬度 | 訂貨號 | 缸徑 | 溝槽底徑 | 寬度 | ||||||
| DN H9 | d1 h9 | L1+0.2 | DN H9 | d1 h9 | L1+0.2 | ||||||||
| GSD0080 | 8 |
3.1 |
2.2 |
GSD2500 | 250 |
229.5 |
8.1 |
||||||
| GSD0100 | 10 |
5.1 |
2.2 |
GSD2500/1 | 250 |
226.0 |
8.1 |
||||||
| GSD0120 | 12 |
7.1 |
2.2 |
GSD2560 | 256 |
232.0 |
8.1 |
||||||
| GSD0150 | 15 |
10.1 |
2.2 |
GSD2600 | 260 |
236.0 |
8.1 |
||||||
| GSD0180 | 18 |
10.7 |
3.2 |
GSD2700 | 270 |
246.0 |
8.1 |
||||||
| GSD0200/1 | 20 |
15.1 |
2.2 |
GSD2800 | 280 |
256.0 |
8.1 |
||||||
| GSD0200 | 20 |
12.7 |
3.2 |
GSD2900 | 290 |
266.0 |
8.1 |
||||||
| GSD0220 | 22 |
14.7 |
3.2 |
GSD3000 | 300 |
276.0 |
8.1 |
||||||
| GSD0250 | 25 |
17.7 |
3.2 |
GSD3100 | 310 |
286.0 |
8.1 |
||||||
| GSD0270 | 27 |
16.3 |
4.2 |
GSD3200 | 320 |
299.5 |
8.1 |
||||||
| GSD0280 | 28 |
17.3 |
4.2 |
GSD3200/1 | 320 |
296.0 |
8.1 |
||||||
| GSD0300 | 30 |
19.3 |
4.2 |
GSD3300 | 330 |
306.0 |
8.1 |
||||||
| GSD0320/1 | 32 |
24.7 |
3.2 |
GSD3400 | 340 |
316.0 |
8.1 |
||||||
| GSD0320 | 32 |
21.3 |
4.2 |
GSD3500 | 350 |
326.0 |
8.1 |
||||||
| GSD0350 | 35 |
24.3 |
4.2 |
GSD3600 | 360 |
336.0 |
8.1 |
||||||
| GSD0360 | 36 |
25.3 |
4.2 |
GSD3700 | 370 |
346.0 |
8.1 |
||||||
| GSD0380 | 38 |
27.3 |
4.2 |
GSD3800 | 380 |
356.0 |
8.1 |
||||||
| GSD0400/1 | 40 |
32.7 |
3.2 |
GSD3900 | 390 |
366.0 |
8.1 |
||||||
| GSD0400 | 40 |
29.3 |
4.2 |
GSD4000 | 400 |
376.0 |
8.1 |
||||||
| GSD0450 | 45 |
34.3 |
4.2 |
GSD4100 | 410 |
386.0 |
8.1 |
||||||
| GSD0480 | 48 |
37.3 |
4.2 |
GSD4200 | 420 |
396.0 |
8.1 |
||||||
| GSD0500 | 50 |
39.3 |
4.2 |
GSD4300 | 430 |
406.0 |
8.1 |
||||||
| GSD0500/1 | 50 |
34.9 |
6.3 |
GSD4400 | 440 |
416.0 |
8.1 |
||||||
| GSD0520 | 52 |
41.3 |
4.2 |
GSD4500 | 450 |
426.0 |
8.1 |
||||||
| GSD0550 | 55 |
44.3 |
4.2 |
GSD4600 | 460 |
436.0 |
8.1 |
||||||
| GSD0600 | 60 |
44.9 |
6.3 |
GSD4700 | 470 |
446.0 |
8.1 |
||||||
| GSD0630/1 | 63 |
52.3 |
4.2 |
GSD4800 | 480 |
456.0 |
8.1 |
||||||
| GSD0630 | 63 |
47.9 |
6.3 |
GSD4900 | 490 |
466.0 |
8.1 |
||||||
| GSD0640 | 64 |
48.9 |
6.3 |
GSD5000 | 500 |
476.0 |
8.1 |
||||||
| GSD0650 | 65 |
49.9 |
6.3 |
GSD5100 | 510 |
486.0 |
8.1 |
||||||
| GSD0700/1 | 70 |
59.3 |
4.2 |
GSD5200 | 520 |
496.0 |
8.1 |
||||||
| GSD0700 | 70 |
54.9 |
6.3 |
GSD5300 | 530 |
506.0 |
8.1 |
||||||
| GSD0750 | 75 |
59.9 |
6.3 |
GSD5400 | 540 |
516.0 |
8.1 |
||||||
| GSD0800 | 80 |
64.9 |
6.3 |
GSD5500 | 550 |
526.0 |
8.1 |
||||||
| GSD0800/1 | 80 |
59.5 |
8.1 |
GSD5600 | 560 |
536.0 |
8.1 |
||||||
| GSD0850 | 85 |
69.9 |
6.3 |
GSD5700 | 570 |
546.0 |
8.1 |
||||||
| GSD0900 | 90 |
74.9 |
6.3 |
GSD5800 | 580 |
556.0 |
8.1 |
||||||
| GSD0900/1 | 90 |
69.5 |
8.1 |
GSD5900 | 590 |
566.0 |
8.1 |
||||||
| GSD0950 | 95 |
79.9 |
6.3 |
GSD6000 | 600 |
576.0 |
8.1 |
||||||
| GSD0950/1 | 95 |
74.5 |
8.1 |
GSD6100 | 610 |
586.0 |
8.1 |
||||||
| GSD1000 | 100 |
84.5 |
6.3 |
GSD6200 | 620 |
596.0 |
8.1 |
||||||
| GSD1000/1 | 100 |
79.5 |
8.1 |
GSD6300 | 630 |
606.0 |
8.1 |
||||||
| GSD1100 | 110 |
94.9 |
6.3 |
GSD6400 | 640 |
616.0 |
8.1 |
||||||
| GSD1200 | 120 |
104.9 |
6.3 |
GSD6500 | 650 |
626.0 |
8.1 |
||||||
| GSD1250 | 125 |
104.5 |
6.3 |
GSD6600 | 660 |
636.0 |
8.1 |
||||||
| GSD1250/1 | 125 |
104.9 |
8.1 |
GSD6700 | 670 |
642.7 |
9.5 |
||||||
| GSD1300 | 130 |
114.9 |
6.3 |
GSD6800 | 680 |
652.7 |
9.5 |
||||||
| GSD1350 | 135 |
119.9 |
6.3 |
GSD6900 | 690 |
662.7 |
9.5 |
||||||
| GSD1400 | 140 |
124.9 |
6.3 |
GSD7000 | 700 |
672.7 |
9.5 |
||||||
| GSD1450 | 145 |
129.9 |
6.3 |
GSD7100 | 710 |
682.7 |
9.5 |
||||||
| GSD1500 | 150 |
134.9 |
6.3 |
GSD7200 | 720 |
692.7 |
9.5 |
||||||
| GSD1550 | 155 |
139.9 |
6.3 |
GSD7300 | 730 |
702.7 |
9.5 |
||||||
| GSD1600 | 160 |
144.9 |
6.3 |
GSD7400 | 740 |
712.7 |
9.5 |
||||||
| GSD1600/1 | 160 |
139.5 |
8.1 |
GSD7500 | 750 |
722.7 |
9.5 |
||||||
| GSD1650 | 165 |
149.9 |
6.3 |
GSD7600 | 760 |
732.7 |
9.5 |
||||||
| GSD1700 | 170 |
154.9 |
6.3 |
GSD7700 | 770 |
742.7 |
9.5 |
||||||
| GSD1750 | 175 |
159.9 |
6.3 |
GSD7800 | 780 |
752.7 |
9.5 |
||||||
| GSD1800 | 180 |
164.9 |
6.3 |
GSD7900 | 790 |
762.7 |
9.5 |
||||||
| GSD1800/1 | 180 |
159.5 |
8.1 |
GSD8000 | 800 |
772.7 |
9.5 |
||||||
| GSD1900 | 190 |
174.9 |
6.3 |
GSD9000 | 900 |
872.7 |
9.5 |
||||||
| GSD1900/1 | 190 |
169.5 |
8.1 |
GSD9200 | 920 |
892.7 |
9.5 |
||||||
| GSD2000 | 200 |
184.9 |
6.3 |
GSD10000 | 1000 |
972.7 |
9.5 |
||||||
| GSD2000/1 | 200 |
179.5 |
8.1 |
GSD10000/1 | 1000 |
962.0 |
13.8 |
||||||
| GSD2100 | 210 |
189.5 |
8.1 |
GSD12000 | 1200 |
1172.7 |
9.5 |
||||||
| GSD2200 | 220 |
204.9 |
6.3 |
GSD12000/1 | 1200 |
1162.0 |
13.8 |
||||||
| GSD2200/1 | 220 |
199.5 |
8.1 |
GSD15000 | 1500 |
1462.0 |
13.8 |
||||||
| GSD2300 | 230 |
209.5 |
8.1 |
GSD16000 | 1600 |
1562.0 |
13.8 |
||||||
| GSD2400 | 240 |
219.5 |
8.1 |
GSD20000 | 2000 |
1962.0 |
13.8 |
||||||
